Test Service

Collaboration diagram for Test Service:

Data Structures
struct	m0_net_test_service_cmd_handler
struct	m0_net_test_service_ops
struct	m0_net_test_service

Enumerations
enum	m0_net_test_service_state {   M0_NET_TEST_SERVICE_UNINITIALIZED = 0, M0_NET_TEST_SERVICE_READY, M0_NET_TEST_SERVICE_FINISHED, M0_NET_TEST_SERVICE_FAILED,   M0_NET_TEST_SERVICE_NR }

Functions
int	m0_net_test_service_init (struct m0_net_test_service *svc, struct m0_net_test_service_ops *ops)
void	m0_net_test_service_fini (struct m0_net_test_service *svc)
bool	m0_net_test_service_invariant (struct m0_net_test_service *svc)
int	m0_net_test_service_step (struct m0_net_test_service *svc)
int	m0_net_test_service_cmd_handle (struct m0_net_test_service *svc, struct m0_net_test_cmd *cmd, struct m0_net_test_cmd *reply)
void	m0_net_test_service_state_change (struct m0_net_test_service *svc, enum m0_net_test_service_state state)
enum m0_net_test_service_state	m0_net_test_service_state_get (struct m0_net_test_service *svc)

Detailed Description

Test services:

• ping test client/server;
• bulk test client/server;

See also

Motr Network Benchmark

Enumeration Type Documentation

m0_net_test_service_state

enum m0_net_test_service_state

Service state

Enumerator
M0_NET_TEST_SERVICE_UNINITIALIZED	Service is not initialized
M0_NET_TEST_SERVICE_READY	Service is ready to handle commands
M0_NET_TEST_SERVICE_FINISHED	Service was finished. Can be set by service operations
M0_NET_TEST_SERVICE_FAILED	Service was failed. Can be set by service operations
M0_NET_TEST_SERVICE_NR	Number of service states

Definition at line 60 of file service.h.

Function Documentation

m0_net_test_service_cmd_handle()

int m0_net_test_service_cmd_handle	(	struct m0_net_test_service *	svc,
		struct m0_net_test_cmd *	cmd,
		struct m0_net_test_cmd *	reply
	)

Handle command and fill reply

Precondition

m0_net_test_service_invariant(svc)

Postcondition

m0_net_test_service_invariant(svc)

Definition at line 121 of file service.c.

Here is the call graph for this function:

Here is the caller graph for this function:

m0_net_test_service_fini()

void m0_net_test_service_fini

(

struct m0_net_test_service *

svc

)

Finalize test service. Service can be finalized from any state except M0_NET_TEST_SERVICE_UNINITIALIZED.

Precondition

m0_net_test_service_invariant(svc)

(svc->nts_state != M0_NET_TEST_SERVICE_UNINITIALIZED)

Postcondition

m0_net_test_service_invariant(svc)

Definition at line 88 of file service.c.

Here is the call graph for this function:

Here is the caller graph for this function:

m0_net_test_service_init()

int m0_net_test_service_init	(	struct m0_net_test_service *	svc,
		struct m0_net_test_service_ops *	ops
	)

Initialize test service. Typical pattern to use test service:

m0_net_test_service_init();
while (state != FAILED && state != FINISHED) {
        command_was_received = try_to_receive_command();
        if (command_was_received)
        m0_net_test_service_cmd_handle(received_command);
        else
        m0_net_test_service_step();
}
m0_net_test_service_fini();

Note

Service state will not be changed if ops->ntso_init returns non-zero result and will be changed to M0_NET_TEST_SERVICE_READY otherwise.

Parameters

svc	Test service
ops	Service operations

Postcondition

ergo(result == 0, m0_net_test_service_invariant(svc))

Definition at line 68 of file service.c.

Here is the call graph for this function:

Here is the caller graph for this function:

m0_net_test_service_invariant()

bool m0_net_test_service_invariant

(

struct m0_net_test_service *

svc

)

Test service invariant.

Definition at line 98 of file service.c.

Here is the caller graph for this function:

m0_net_test_service_state_change()

void m0_net_test_service_state_change	(	struct m0_net_test_service *	svc,
		enum m0_net_test_service_state	state
	)

Change service state. Can be called from service ops.

Precondition

m0_net_test_service_invariant(svc)

Postcondition

m0_net_test_service_invariant(svc)

Definition at line 147 of file service.c.

Here is the call graph for this function:

Here is the caller graph for this function:

m0_net_test_service_state_get()

enum m0_net_test_service_state m0_net_test_service_state_get

(

struct m0_net_test_service *

svc

)

Get service state.

Precondition

m0_net_test_service_invariant(svc)

Definition at line 159 of file service.c.

Here is the call graph for this function:

Here is the caller graph for this function:

m0_net_test_service_step()

int m0_net_test_service_step

(

struct m0_net_test_service *

svc

)

Take one step. It can be only done from M0_NET_TEST_SERVICE_READY state.

Precondition

m0_net_test_service_invariant(svc)

Postcondition

m0_net_test_service_invariant(svc)

Definition at line 107 of file service.c.

Here is the call graph for this function:

Here is the caller graph for this function:
